About this part

NIBCO S-585-70 is a two-piece full-port bronze ball valve with solder ends for use in commercial and industrial piping systems. It features a blowout-proof stem, PTFE packing and seats, and is rated for 600 PSI cold working pressure or 150 PSI steam service. The valve is suitable for a wide range of water, oil, and gas applications where reliable shutoff is required.

  • 1" nominal size, solder (CxC) ends
  • Full port, two-piece body, bronze trim
  • 600 PSI/41.4 bar non-shock cold working pressure
  • 150 PSI/10.3 bar saturated steam rating
  • Cast red bronze body ASTM B 584 Alloy C84400
  • Reinforced PTFE seats and packing, silicon bronze stem
  • Conforms to MSS SP-110, lead-free option available

Specifications

Brand
Nibco Valves
Part number
S-585-70
SKU
1187578
Category
Ball Valves
Shipping weight
1.78 lb

Not sure it's the right part? Send us the old part number or a photo and we'll check.
